3 Axle Tandem Rocker Axle Trailer Suspension Q235 60mm Hole OEM

3 Axle German BPW type of semi trailer suspension

The product description:

1. Easy attachment to the chassis and simple transversal and longitudinal bracing due to the practical and solid design of the mounting brackets.

2. Use of high-strength, weldrable mounting bracket material permits a homogeneous weld without the need for special welding instructions.

3. Maintenance-free, adjustable torque rods supported by rubber/metal bushings(1*per axle) permit simple, precise track adjustment. This possibility simplifies the attachment of the suspension to the chassis and has a positive influence on the service life of the tyres.

4. Available with axle capacities of12 to 48tons in single, tandem or tridem suspension configuration.(higher loads on your request)

Note:

1. Leaf spring size:100mm Width *12mm Thickness *12Pcs

2. Weight:1120kg (consist of 6 sets leaf spring)

3. Balance arm pin: 60 or 70

4. Thickness: 8mm, 10mm

5. Mount Height: 142 mm

6. Material: Q235

7. Certificate: ISO9001

8.Single-axle, double-axle, and 3-axle German type mechanical suspensions

9.Axle load capacity of 12ton, 14ton or 16tons.

10.Quantity and width of leaf spring and wheelbase is optional by your request;

11. Suitable for square 150mm axles, Φ127 round axle.

Trailer Suspension
1, Reliable proven design
2, Australia ADR approved
3, Greaseless powdered metal bushing for high durability
4, High strength material for longer life at higher loads
5, Simple maintenance

Axle Trailer Suspension Q235

black Axle Trailer Suspension 60mm hole

3 Axle tandem rocker suspension oem

3 Axle Tandem Rocker Axle Trailer Suspension Q235 60mm Hole OEM Images
